The ARCHMI-919B series features a powerful built-in Intel Whiskey Lake 8th generation energy efficient core i3/i5 processor with up to 32GB of DDR4 RAM. The ARCHMI-919B series has a wide range of rugged industrial features and customisable options which makes it ideal for a wide variety of industrial applications, including manufacturing, warehousing and process control.

The IP66 certified front panel provides water and dust protection, ideal for harsh environments. The ARCHMI-919B also features a rugged fanless aluminium die-cast chassis, and a compact profile ideal for space-saving applications. The overall rugged design of the ARCHMI-919B series provides 24/7 reliability, makes it easy to clean, reduces maintenance cost, and provides a long-lasting rugged solution.

The ARCHMI-919B features a 19” TFT-LCD with a 1280 x 1024 resolution. A range of other screen sizes (12.1”-32”) are also available in the ARCHMI-9B series. The optional projected capacitive touch screen with multi-touch support, and anti-scratch surface helps to improve usability, while also providing the screen with tough protection. Optional auto dimming, 1,000nits high brightness, and optical bonding, makes the ARCHMI-919B perfect for a range of applications, no matter the environment or weather.

The ARCHMI-919B offers a wide range of optional expansions to suit your needs including 4G, WiFi, CAN bus, additional Serial, LAN or USB ports. It also offers the optional smart battery backup feature. This provides up to 30 minutes (depending on usage) of emergency backup power for any unexpected power interruptions. It can be panel or VESA mounted, allowing the system to be ergonomically positioned for operator convenience.

Key Features:

  • Intel 8th Gen. Core i3 / i5 built-in
  • 1 x 260Pin SO-DIMM DDR4 up to 32GB 2400MHz
  • Flat Front Panel meets IP66
  • Aluminum Die-Casting Chassis Fanless Design
  • DC 9~36V Wide-Ranging Power Input
  • Optional High Brightness 1000nit
  • Supports Expansion via Full-size Mini PCIe and M.2 slots
  • 19" TFT-LCD Resistive / Projected Capacitive Touch

Data Sheets (PDF)

Product Downloads PDF Icon

ARCHMI-919B Series Data Sheet

Product Information

Part Numbers



19inch 1280x1024 fanless PanelPC, Intel i3-8145UE 2.2GHz processor, resistive touchscreen, 4 USB3.0, 2 Gbe, 2 ser, audio, M.2 ssd, 1xMini-PCIe, M.2 2230, 9-36VDC input


19inch 1280x1024 fanless PanelPC, Intel i3-8145UE 2.2GHz processor, proj cap touchscreen, 4 USB3.0, 2 Gbe, 2 ser, audio, M.2 ssd, 1xMini-PCIe, M.2 2230, 9-36VDC input

Processor Upgrade Options



Upgrade from i3-8145UE 2.2GHz 2C/4T to i5-8365UE 1.6GHz 4C/8T CPU

Memory Options



4GB RAM for ARCHMI-9xxB series


8GB RAM for ARCHMI-9xxB series


16GB RAM for ARCHMI-9xxB series
