BOXER-6645U-RPL

The BOXER-6645U-RPL is a rugged fanless embedded box PC that has been designed with a range of rugged features, along with high-performance computing capabilities. It features 12th/13th/14th Generation Intel Core i3/i5/i7/i9 socket-type processor options with Intel H610E chipset, as well as two DDR5 SODIMM slots for up to 64 GB of memory. It also features two 2.5” SATA drive bays and one M.2 2280 M-Key for NVMe. With these features combined, the BOXER-6645U-RPL is an ideal embedded solution for applications that require high-performance computing.

The BOXER-6645U-RPL also features a range of I/O, expansion and OS options, making it adaptable to a wide variety of industrial applications. It comes with four USB 3.2 Gen 2, two USB 2.0, two DB-9 for RS-232/422/485, two HDMI, and two Gbe LAN. It also features the following expansion options, one M.2 2280 M-Key (For NVMe Storage), one M.2 2230 E-Key (for Wi-Fi/Bluetooth), and one Full Size MiniPCIe (optional for mSATA). It also supports the following OS, Windows 10 IoT, Windows 11 Pro, and Linux Ubuntu.

The BOXER-6645U-RPL has also been designed with a number of rugged features including, an ultra-wide operating temperature range (up to -25°C ~ 70°C), anti-shock & anti-vibration protection, a rugged housing that provides protection against dust and other environmental factors, and a 10~35 VDC power input range. It also has a compact form factor (180mm x 77.2mm x 220mm), which makes it ideal for applications with limited space.

Download the data sheet for more technical details, and/or contact us via the “Request a Quote” tab.

Key Features:

• 12/13/14th Generation Intel® Core™ LGA 1700 Socket-Type
• Processor with Intel® H610E Chipset
• Wide Operating Temperature (-25°C ~ 70°C)
• 2 x HDMI Output
• 2 x GbE LAN
• 4 x USB 3.2 Gen; 2 x USB2.0
• 2 x RS-232/422/485, 4 x RS-232 (Optional)
• 2 x Internal 2.5" SSD Bay
• 10~35 VDC Power Input Range
• Supports Windows 10/11 & Linux Ubuntu
• Anti-Shock & Anti-Vibration protection
