RTC-M102

The RTC-M102 is a rugged 10.1” Android tablet designed for demanding field and industrial applications, offering a balance of high performance, durability, and mobility. Its 10.1-inch TFT LCD features a 1280 x 800 resolution (1920 x 1200 optional) with up to 700nits brightness, providing clear and vibrant visuals even in bright sunlight. The G+G capacitive multi-touch screen with Gorilla Glass and 7H hardness supports glove and wet-touch operation, making it ideal for outdoor and industrial environments.

Powered by a MediaTek MT8781 Octa-core processor, combining a dual-core ARM Cortex-A76 (2.2 GHz) and a hexa-core ARM Cortex-A55 (2.0 GHz), the RTC-M102 delivers smooth and responsive performance for data collection, mapping, inspections, logistics, and other mobile workflows. It comes equipped with 8GB of memory and 128GB of internal storage, providing ample capacity for apps, documents, and multimedia. Integrated ARM Mali-G57 graphics enable seamless visualisation of data, maps, and multimedia content. Front (5MP) and rear (13MP with flash) cameras support documentation, remote support, and field reporting, while a full sensor suite including compass, gyroscope, G-sensor, and light sensor enhances operational awareness.

The RTC-M102 features versatile connectivity and optional data capture modules. It includes 1 x USB 2.0 Type-A and 1 x USB 2.0 Type-C (supporting power and data), 1 x RJ45 Ethernet, a Micro SIM slot, and a TF card slot for additional storage up to 256GB. Optional aviation plugs allow flexible configuration, including USB or RS232 connections, tailored to specific industrial workflows. Data capture options include NFC, optional 1D/2D barcode scanning, RFID, and fingerprint authentication for secure and efficient field operations. Wireless connectivity is provided via dual-band Wi-Fi, Bluetooth 5.2, 4G/5G cellular, and GNSS positioning using GPS, GLONASS, and BeiDou.

Built for extreme conditions, the RTC-M102 includes a removable 10,000 mAh lithium-ion polymer battery, offering up to 8 hours of operation. It operates reliably in wide temperature ranges from -10°C to 50°C, is certified to MIL-STD-810H standards for shock and vibration and has an IP67 rating for dust and water resistance, ensuring dependable performance in harsh environments. With Android 16, strong connectivity, advanced security options, and rugged design, the RTC-M102 is ideal for a range of industrial and mobile applications where durability, efficiency, and real-time data capture are essential.

To learn more, download the datasheet or request a quote today.

Key Features:

• 10.1" TFT LCD, 1280 x 800 (optional 1920 x 1200), 700nits brightness
• G+G capacitive multi-touch with Gorilla Glass (7H hardness), glove/wet support
• MediaTek MT8781 Octa-core processor with ARM Mali-G57 graphics
• IP67 dust and water protection
• 8GB RAM, 128GB storage
• Front 5MP and rear 13MP cameras with flash
• NFC, optional 1D/2D barcode scanner, RFID, and fingerprint modules
• USB 1 x Type-A/ 1 x Type-C, 1 x RJ45 Ethernet
• Micro SIM and TF card slot (up to 256GB)
• Optional aviation plug configuration for USB or RS232
• Wi-Fi, Bluetooth 5.2, 4G/5G cellular, GNSS (GPS, GLONASS, BeiDou)
• Removable 10,000mAh battery, up to 8h operation
• Operating temperature: -10°C to 50°C
• MIL-STD-810H shock and vibration certified
• Android 16 operating system
